Electro Permanent Magnetic Lifters
Is moving steel plate, rounds and blocks wasting precious time? Is manual lifting causing back injuries? Are slow machine set-ups
cutting into machine output?
If the answer to any of these questions is "YES", SHENGANG-Lift
lifting magnets are for you!
SHENGANG-Lift magnets are the fastest and safest way to transport
raw stock and workpieces.
From theLittle SG weighting only 100kg that can safely lift 100kg, with a 3.5X safety
factor!
To the Big SG that lifts up to 2000kg with a 3.5X safety factor!
SHENGNG-LIFT LIFTING MAGNET APPLICATIONS:
Move plate steel, block or round steel and iron material in your shop easily and safely.
Load machines faster. Load most work pieces to save time and boost production. It's
perfect for loading or unloading press molds, plastic molds,
machined parts and other ferrous parts and materials.
Fastest and safest way to lift without dangerous slings.
No electricity required. Super-powerful "rare earth" neodymium iron boron magnets require
no electricity. There is no risk in losing lifting force even
during power failures.
It is used to lift and transfer the normal temperature steel plates
in ship-making industry, engineering mechanical industry, automobile
industry and so on. There have three series of YX and YC according to their material
unloading modes.
SHENGANG LIFTING MAGNET FEATURES :
Rated for loads up to 1000KG. Powerful magnet tested to hold 3.5 TIMES the rated load for maximum
safety. Eliminates dangerous straps and slings. For fast, safe, efficient machine loading and unloading
|
SHENGANG PERMANENT LITING MAGNETS MAGNT LIFTER OPERATION:
First center the magnet on the piece to be lifted. Then simply move
the lever to the "ON" position to engage the magnet. Spring-loaded
lock keeps magnet engaged until you release it.
BENEFITS: SAFE MATERIAL HANDLING & INCREASED PRODUCTIVITY
MAXIMUM RATED LOADS:
Calculate that the magnet will safely lift your material. The
Maximum Load (ML) is different for plate and round materials and
also depends upon stock thickness, carbon content, and surface
finish. Use these formulas and tables to calculate the ML for your
material type.
YC-1 Permanent Lifting Magnets Magnet Lifter Main Technical Data:
| Model | Max.Attraction Force(Kg) | Rated Lifting Capacity(Kg) | Overall Dimension(mm) | Weight(Kg) |
| A | B | C | D |
| YC1-0.2 | 600 | 200 | 130 | 110 | 124 | 250 | 12 |
| YC1-0.3 | 900 | 300 | 180 | 110 | 124 | 270 | 16 |
| YC1-0.5 | 1500 | 500 | 258 | 110 | 124 | 380 | 25 |
| YC1-1 | 3000 | 1000 | 263 | 180 | 219 | 412 | 68 |
| YC1-2 | 6000 | 2000 | 288 | 220 | 269 | 552 | 150 |
YC-1 Permanent Magnetic Lifter Overall Dimension:
Standard Export Package :
(fixed iron frame with five-plywoodboard packing to keep safety and
long-distance transportation)
Quick Response:
We highly appreciate your any enquiry by email, fax or instant message.
We will reply your email or fax within 24 hours.
Please fell free to call us at any time if there is any questions.
Convenient Transportation:
All available shipping ways could be applied, by courier, air or sea.
Appointed shipping company or our own forwarders all could be used in shipment.
Full-way tracking the cargos for you till the goods arrive.
